SPECIFICATION / 01
Technical Info
Main Source
440W RGBWLA, 90° beam angle
Secondary Source
40W RGBW, 3.8° beam angle
Combined Output
8,000 lumens
Colour Temperature
2000-6500K (main), 6000K (secondary)
CRI
>95 (calibrated mode)
IP Rating
IP65
Power Consumption
Max 450W, 100-240V
Dimming
16-bit, 12.5kHz refresh
DMX Modes
8 modes, 8-28 channels
Weight
14kg
Dimming
16-bit dimming and colour mixing
Control protocols
DMX512, RDM; optional CRMX
DMX channels / modes
8 modes, 8–28 channels
IP rating
IP65
Power requirements
100–240 V AC, 50/60 Hz; 450 W
Mounting
Tilt yoke; optional omega bracket
Dimensions
400 × 440 × 290 mm
Weight
14 kg
Product video
PRODUCT NOTES / 02
Additional Information
The Portman Lights OmniRay is a weatherproof hybrid fixture combining a 440W RGBWLA main source with a 90-degree beam angle for broad wash coverage, and a secondary 40W RGBW source with a tight 3.8-degree beam for punchy accent or blinder effects, all from one IP65-rated housing.
With colour temperature adjustable from 2000K to 6500K, CRI above 95 in calibrated mode, 16-bit dimming and a 12.5kHz flicker-free refresh rate, it delivers 8,000 lumens of combined output and includes a Colour Feedback System for remote status monitoring, with 8 selectable DMX modes from 8 to 28 channels.
