SPECIFICATION / 01
Technical Info
Power Output
1100W dynamic (700W continuous)
Driver Configuration
12in LF woofer, 1.4in HF compression driver
Frequency Response
52Hz - 20kHz (-10dB)
Maximum SPL
132dB at 1m
Coverage
90° x 60° constant directivity horn
DSP
FIR-X tuning, D-CONTOUR multi-band processing, 48-bit
Crossover Frequency
2.1kHz
Inputs
XLR, 2x phone jack, 2x RCA, 3-channel onboard mixer
Outputs
XLR thru, XLR link
Weight
19.3kg
Power Supply
Universal 100-240V
Product video
PRODUCT NOTES / 02
Additional Information
The Yamaha DXR12 is a 2-way bi-amplified powered speaker combining a 12-inch woofer with a 1.4-inch compression driver on a 90x60 degree constant-directivity horn, delivering 1100W dynamic power (700W continuous) and up to 132dB SPL at 1m for bands, DJs and corporate PA applications.
Yamaha’s FIR-X linear-phase DSP crossover and D-CONTOUR multi-band dynamic processing (with FOH/Main, Monitor and Off modes) keep the sound controlled and consistent across volume levels, while onboard XLR and jack/RCA inputs with a 3-channel mixer make it usable as a standalone PA or stage monitor without an external desk.
