SPECIFICATION / 01
Technical Info
Light Source
7 x 40W RGBW multichip, 20 x 10W white strobe LEDs
LED Life
50,000 hours minimum
Power Consumption
Max 330W, 100-240V auto-ranging
Zoom Range
3.8° - 50° (13:1 ratio)
Output
11,000lm (integrating sphere) / 8,600lm (goniophotometer, max zoom)
DMX Modes
3 modes: 28, 58 or 61 channels, 8/16-bit
Weight
7.2kg
Tilt range
360° with continuous rotation
Strobe
20 dedicated white strobe LEDs
Dimming
8- or 16-bit; internal 18-bit
Control protocols
DMX, RDM, Art-Net, sACN, MA-Net; optional CRMX
DMX channels / modes
28, 58 or 61 channels
Data connections
5-pin XLR DMX; optional Ethernet
IP rating
IP20
Power requirements
100–240 V AC, 50/60 Hz; maximum 330 W
Dimensions
281 × 398 × 186 mm
Weight
7.2 kg
Product video
PRODUCT NOTES / 02
Additional Information
The Robe SVB1 is a compact, lightweight beam/wash/strobe hybrid moving light combining 7 x 40W RGBW multichip LEDs with 20 x 10W white strobe LEDs, giving punchy strobe effects alongside smooth colour wash from a fixture weighing just 7.2kg.
Its motorised zoom spans 3.8-50 degrees with a 13:1 ratio, delivering up to 11,000 lumens (integrating sphere), and 3 selectable DMX protocol modes (28, 58 or 61 channels) with 8 or 16-bit resolution give flexible integration for touring rigs where size and weight matter.
