SPECIFICATION / 01
Technical Info
Product type
Manual winch-operated telescopic ground support lifter
Maximum height
5.35m
Maximum load
250kg
Maximum footprint
2.16 x 2.16m
Transport size
1.74m
Weight
80kg
Operation
AL-KO steel cable winch, 2-position KAT lock
Adaptor fitment
50mm diameter female
Safety standards
BGV C1, CE 2006/42/CE
PRODUCT NOTES / 02
Additional Information
The Kuzar K-5 Telescopic Lifter is a manually winched ground-support tower capable of raising loads up to 250kg to a maximum height of 5.35m, making it a practical alternative to motorised hoists or cranes for lifting LED video panels, lighting rigs and small truss structures into position. It uses AL-KO winches loaded with steel cable, with a two-position KAT lock system for raising and safely locking the lifter at height.
The lifter has a maximum footprint of 2.16 x 2.16m when deployed, collapsing to a 1.74m transport size, and weighs 80kg. It accepts a 50mm diameter female adaptor fitment for mounting truss or fixtures, and is manufactured in Europe to BGV C1 and CE (2006/42/CE) safety standards for professional event and rental use.
